Bender ISOMETER isoRW425 User Manual

65
isoRW425_D00052_03_M_XXEN / 02.2017
9. IsoData data string
In IsoData mode, the ISOMETER® continuosly sends the whole data string
with a cycle time of approximately 1 second. Communication with the ISOME-
TER® within this mode is not possible and no additional sender may be con-
nected via the RS-485 bus cable.
IsoData is activated in the menu "out", menu item "Adr" when it has been set
to Adr = 0. In this event, the symbol "Adr" flashes on the measuring value dis-
play.
String Description
!; Start symbol
v; Insulation fault location ' ' / '+' / '-'
1234, 5; Insulation resistance R
F
[k]
1234; Leakage capacitance C
e
R mode [µF] / Z mode [nF]
1234, 5; Insulation impedance Z
F
[k]
+1234;
Mains voltage U
n
[V
RMS
]
Mains voltage type: AC or unknown: ' ' DC: '+' / '-'
+1234; Mains voltage U
L1e
[V
DC
]
+1234; Mains voltage U
L2e
[V
DC
]
+123; Insulation fault location -100 … +100 [%]
