BendPak 10AP - 5595793; Sheet1; Drawing View2

7773
S
4.8
2
1
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5595749 SAFETY CABLE Ø1.8 7773mm* -
2 5580030 Ø1.8 CABLE END CRIMP 1 -
NEXT ASSEMBLY
5250343
WHERE USED
10AP
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE, DERIVED FROM 5595705 06/15/2022 CA 01417
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
A
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
CA
5595793
SAFETY CABLE
Ø1.8 x 7773mm
06/15/2022
DO NOT SCALE DRAWING
1:1
SCALE:
THIRD ANGLE PROJECTION
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±0.5
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED .
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
FOR ITEM 1 AND 2 SPECIFICATIONS REFER TO PART 2.
SPECIFICATION FORM
