ISOMETRIC VIEW
FOR REFERENCE ONLY
DO NOT SCALE
24.0
7 PL
31.0
3 PL
31.0
4 PL
135.9
2 PL
433.0
2 PL
142.5
2 PL
495.0
90.0
2 PL
36.6
2 PL
R6.0
1.5
145.0
2 PL
3.0
143.0
37.0°
2 PL
166.9
2 PL
54.2
2 PL
16.0
346
NEXT ASSEMBLY
5601800
5601812
5601850
5601581
WHERE USED
10AP SERIES
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
A
PRODUCTION RELEASE, DERIVED FROM 5737179
07/06/2022
CA
01417
B
WAS Ø22.0 NOQ Ø24.0
04/20/2023
TM
01488
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
B
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED.
CA
DIMENSIONS ARE IN MM
TOLERANCES: MACHINE TO
0 = ±1.5
0.0 = ±0.5
0.00 = ±0.13
SURFACE FINISH 1.6 Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
5731073
10AP BASE PLATE
DO NOT SCALE DRAWING
1:5
SCALE:
THIRD ANGLE PROJECTION
OR
04/28/2023
REFER TO MODEL FOR ADDITIONAL INFORMATION
1.
BREAK AND DEBURR ALL SHARP EDGES 0.3mm
2.
MATERIAL:
HR ASTM A36 OR Q235 GB/T 700
3.
06/30/2022
