P45 Motor Overload Class Starting PFN 14
LED Display LCD Display
Range Off, 1 – 40 (Default class 10)
Description The Motor Overload Class Starting parameter sets the class of the electronic overload when starting. The
starter stores the thermal overload value as a percentage value between 0 and 100%, with 0% representing a
“cold” overload and 100% representing a tripped overload.
The starting overload class is active during Kicking and Ramping when the Independent Starting/Running
Overload (P44 / PFN 13) parameter is set to “On”.
When the Motor Starting Overload Class parameter is set to "Off", the electronic overload is disabled while
starting the motor.
z NOTE: Care must be taken not to damage the motor when turning the starting overload class off or setting
to a high value.
z NOTE: Consult motor manufacturer data to determine the correct motor OL settings.
See Also Motor Running Overload Class (P3 / QST 03) parameter on page 76.
Independent Starting/Running Overload (P44 / PFN 13) parameter on page 106.
Motor Overload Hot/Cold Ratio (P46 / PFN 16) parameter on page 108.
Motor Overload Cooling Time (P47 / PFN 17) parameter on page 109.
Relay Output Configuration (P52-P54 / I/O 05-07) parameters on page 112.
Theory of Operation section 7.1, Solid State Motor Overload Protection on page 132.
Motor Overload Class Running PFN 15
See Quickstart group QST 03 - Motor Overload Class Running on page 76 for details.
107
6 - PARAMETER DESCRIPTION
PFN: Starting OL
14 10
