5.4.2 Control Function Group
67
5 - PARAMETER GROUPS
Number Display Parameter Setting Range Units Default Page
CFN 00 Jump Code Jump to Parameter 1 to 25 1 83
CFN 01 Start Mode Start Mode
Voltage Ramp
Current Ramp
TT Ramp
Power Ramp
Current Ramp 83
CFN 02 Ramp Time 1 Ramp Time 1 0 to 300 Seconds 15 81
CFN 03 Init Cur 1 Initial Motor Current 1 50 to 600 %FLA 100 79
CFN 04 Max Cur 1 Maximum Motor Current 1 100 to 800 %FLA 600 80
CFN 05 Ramp Time 2 Ramp Time 2 0 to 300 Seconds 15 94
CFN 06 Init Cur 2 Initial Motor Current 2 50 to 600 %FLA 100 93
CFN 07 Max Cur 2 Maximum Motor Current 2 100 to 800 %FLA 600 93
CFN 08 Init V/T/P Initial Voltage/Torque/Power 1 to 100 % 25 84
CFN 09 Max T/P Maximum Torque/Power 10 to 325 % 105 85
CFN 10 Kick Lvl 1 Kick Level 1 Off, 100 to 800 %FLA Off 86
CFN 11 Kick Time 1 Kick Time 1 0.1 to 10.0 Seconds 1.0 86
CFN 12 Kick Lvl 2 Kick Level 2 Off, 100 to 800 %FLA Off 94
CFN 13 Kick Time 2 Kick Time 2 0.1 to 10.0 Seconds 1.0 94
CFN 14 Stop Mode Stop Mode
Coast
Volt Decel
TT Decel
DC Brake
Coast 87
CFN 15 Decel Begin Decel Begin Level 100 to 1 % 40 88
CFN 16 Decel End Decel End Level 99 to 1 % 20 89
CFN 17 Decel Time Decel Time 1 to 180 Seconds 15 90
CFN 18 Brake Level DC Brake Level 10 to 100 % 25 91
CFN 19 Brake Time DC Brake Time 1 to 180 Seconds 5 92
CFN 20 Brake Delay DC Brake Delay 0.1 to 3.0 Seconds 0.2 93
CFN 21 SSpd Speed Slow Speed Off, 7.1, 14.3 % Off 95
CFN 22 SSpd Curr Slow Speed Current Level 10 to 400 % FLA 100 95
CFN 23 SSpd Timer Slow Speed Time Limit Off, 1 to 900 Seconds 10 96
CFN 24 SSpd Kick Curr Slow Speed Kick Level Off, 100 to 800 % FLA Off 96
CFN 25 SSpd Kick T Slow Speed Kick Time 0.1 to 10.0 Seconds 1.0 97
