Jump Code
4.12 Jump Code
At the beginning of each parameter group, there is a Jump Code parameter. By changing the value of this parameter and pressing
[ENTER], you can jump directly to any parameter within that group.
Alphanumeric Display
4.13 Alphanumeric Display
The remote LCD keypad and display uses a 32-character alphanumeric LCD display. All starter functions can be accessed by the
keypad. The keypad allows easy access to starter programming with parameter descriptions on the LCD display.
Power UP Screen
On power up, the software part number is displayed for five seconds. Pressing any key immediately changes the display to the operate
screen.
Operate Screen
The operate screen is the main screen. The Operate screen is used to indicate the status of the starter, if it’s running, what state it’s in,
and display the values of Meter 1 and Meter 2, which are selectable.
The Operate Screen is divided into five sections.
• Sections A and B display status information
• Section C and D displays the meter selected by the Meter 1 and 2 parameters, see FUN 01, 02.
• Section S displays the source for the start command.
54
4 - KEYPAD OPERATION
810023-01-08
K
S T
n
O
o
P
L
P E D
I
V
a
a
=
=
0 .0
0
A
V
SECTION S SECTION C
SECTION B SECTION D
SECTION A
Figure 24: Operate Screen
Display Description
NoL L1, L2, L3 not present
Ready Starter ready to run
Alarm A fault condition is present. If it continues, a fault occurs
Run Starter is running
Table 19: Operate Screen Section A
