Procedure for Setting Data
4.14 Procedure for Setting Data
Select a parameter that is to be changed. To change Motor FLA from 10 Amps to 30 Amps:
From the main screen:
Press [MENU] key and the display shows QST: (Quick Start) screen.
Press [UP] key once to Motor FLA (QST 01).
Press [ENTER] key once, the cursor starts to flash in the one’s place.
Press [LEFT] key once, the cursor flashes in the ten’s place.
Press [UP] arrow to increase the value, for a value of 30, press twice.
Press [ENTER] to store the value.
Press [UP] arrow to change another parameter in QST.
Press [MENU] to change another parameter in another group.
Press [LEFT] arrow to go back to the main screen
58
4 - KEYPAD OPERATION
T Ready Ia= 0.0A
Stopped Va= 480 V
QST: Jump Code
00 1
QST: Motor FLA
01 10 Amp
QST: Motor FLA
01 10 Amp
QST: Motor FLA
01 10 Amp
QST: Motor FLA
01 30 Amp
QST: Motor FLA
01 30 Amp
