BENSHAW RediStart RB2 User Manual

57
4 - KEYPAD OPERATION
Press [MENU] until you get to the FL1 parameter.
Pressing the [UP] and [DOWN] keys navigates through older and newer faults in the log.
Repeatedly pressing the [ENTER] key rotates through the conditions the starter was in when the fault occurred.
4.13.4 Fault Screen
When a Fault occurs, the main screen is replaced with a fault screen. The screen shows the fault number and the name of the fault. The
main status screen is not shown until the fault is reset.
When a fault occurs, the STOP LED flashes.
z NOTE: For a list of the Faults, refer to Appendix B - Fault Codes on page 196.
4.13.5 Lockout Screen
When a lockout is present, one of the following screens will be displayed. The main status screen is not shown until the lockout is
cleared.
The overload lockout displays the overload content The stack over temperature lockout will be displayed
and the time until reset if an overload occurs. if a stack over temperature is detected
.
The control power lockout will be displayed The disconnect open lockout will be displayed if a digital
if the control power is not within specifications. input is programmed to "disconnect" and the input if off.
A "Run Enable or Run Disable" digital input is
set and is not true. See digital inputs on page 110
4.13.6 Alarm Screen
When an alarm is present, the word “Alarm” is displayed on the operate screen. Pressing the [ENTER] key displays more information
about the alarm.
Fault ##
Fault Name
Overload Lockout
96% XX:XX
Stack Overload
Lockout
Control Power
Lockout
Disconnect Open
Lockout
Alarm Number
Alarm Name
Run Interlock
Lockout
Enter Step
1 Fault Description.
2 Status when the fault occurred, Run, Stopped, Accel. etc.
3 The L1 current at the time of the fault.
4 The L2 current at the time of the fault.
5 The L3 current at the time of the fault.
6 L1-2 voltage at the time of the fault.
7 L2-3 voltage at the time of the fault.
8 L3-1 voltage at the time of the fault.
9 kW at the time of the fault.
10 Frequency at the time of the fault.
11 Run time since last run time reset.
