55
4 - KEYPAD OPERATION
4.13.1 Parameter Group Screens
From the operate screen, the parameter group screens are accessed by pressing either the menu or the left arrow keys. The parameter
group screens display the different parameter groups; QST, CFN, PFN, I/O, FUN, FL_.
MMM: = Parameter Group
MI: = Menu Index
PPP: = Parameter Name
VVV: = Parameter Value and Units
Refer to Chapter 5 for a listing of the parameters and their ranges.
Display Description
Stopped Starter is stopped and no Faults
Fault Starter tripped on a Fault
Heater Starter is on and heating motor
Kick Starter is applying kick current to the motor
Accel Starter is accelerating the load
Kick 2 Starter is applying kick current to the motor in Ramp 2
Accel 2 Starter is accelerating the load in Ramp 2
Run Starter is in Run mode and Ramp Time has expired
UTS Starter is Up To Speed
Control Phase Control or Current Follower mode
Decel Starter is decelerating the load
Wye In Wye-delta control indicates motor is accelerating in Wye mode
Slow Spd Fwd Preset slow speed forward
Slow Spd Rev Preset slow speed reverse
Braking DC Injection Braking.
Lockout Starter is Locked Out
Table 20: Operate Screen Section B
Display Description
K Keypad Control
T Terminal Block Control
S Serial Communication Control
Table 21: Operate Screen Section S
MMM: PPPPPPPPPP
MI VVVVVVVVVV
