5PARAMETER GROUPS
Introduction
5.1 Introduction
The MX
2
incorporates a number of parameters that allow you to configure the starter to meet the special requirements of your particular
application. The parameters are organized two ways, depending on the display being used. When the standard, on-board LED display is
used, the parameters are in a single group and numbered P1, P2, P3… etc.
When the remote LCD display is used, the parameters are divided into groups of related functionality, and within the groups the
parameters are identified by a short, descriptive name. The parameters are subdivided into six groups. The groups are QST (Quick
Start), CFN (Control Functions), PFN (Protection Functions), I/O (Input/Output Functions), FUN (Function) and FL1 (Faults) .
The Quick Start Group provides a collection of the parameters that are most commonly changed when commissioning a starter. Many of
the parameters in the Quick Start group are duplicates of the parameters in the other groups.
This chapter lists all of the parameters and their possible values. Section 5.3 lists the parameters in the order in which they appear on the
LED display. Section 5.4 lists them in the order in which they appear on the LCD display. Section 5.2 is a cross-reference between the
two.
60
5 - PARAMETER GROUPS
