5.4.3 Protection Group
5.4.4 I/O Group
68
5 - PARAMETER GROUPS
Number Display Parameter Setting Range Units Default Page
PFN 00 Jump Code Jump to Parameter 1 to 17 1 98
PFN 01 Over Cur Lvl Over Current Trip Level Off, 50 to 800 %FLA Off 98
PFN 02 Over Cur Tim Over Current Trip Delay Time Off, 0.1 to 90.0 Seconds 0.1 99
PFN 03 Undr Cur Lvl Under Current Trip Level Off, 5 to 100 %FLA Off 100
PFN 04 Undr Cur Tim Under Current Trip Delay Time Off, 0.1 to 90.0 Seconds 0.1 100
PFN 05 Cur Imbl Lvl Current Imbalance Trip Level Off, 5 to 40 % 15 101
PFN 06 Gnd Flt Lvl Residual Ground Fault Trip Level Off, 5 to 100 %FLA Off 102
PFN 07 Over Vlt Lvl Over Voltage Trip Level Off, 1 to 40 % Off 103
PFN 08 Undr Vlt Lvl Under Voltage Trip Level Off, 1 to 40 % Off 103
PFN 09 Vlt Trip Tim
Over/Under Voltage Trip Delay
Time
0.1 to 90.0 Seconds 0.1 104
PFN 10 Auto Reset Auto Fault Reset Time Off, 1 to 900 Seconds Off 104
PFN 11 Auto Rst Lim Auto Reset Limit Off, 1 to 10 Off 104
PFN 12 Ctrl Flt En Controlled Fault Stop Enable Off, On On 105
PFN 13 Indep S® OL
Independent Starting/Running
Overload
Off, On Off 106
PFN 14
Starting OL Motor Overload Class Starting
Off, 1 to 40 10 107
PFN 15
Running OL Motor Overload Class Running
Off, 1 to 40 10 76
PFN 16
OL H© Ratio
Motor Overload Hot/Cold Ratio 0 to 99 % 60 108
PFN 17
OL Cool Tim
Motor Overload Cooling Time 1.0 to 999.9 Minutes 30.0 109
Number Display Parameter Setting Range Units Default Page
I/O 00 Jump Code Jump to parameter 1 to 19 1 110
I/O 01 DI 1 Config DI 1 Configuration Off
Stop
Fault High
Fault Low
Fault Reset
Disconnect
Inline Cnfrm
Bypass Cnfrm
E OL Reset
Local/Remote
Heat Disable
Heat Enable
Ramp Select
Slow Spd Fwd
Slow Spd Rev
Brake Disabl
Brake Enable
Run Enable
Run Disable
Stop
110
I/O 02 DI 2 Config DI 2 Configuration Off
I/O 03 DI 3 Config DI 3 Configuration Off
I/O 04 Din Trp Time Digital Fault Input Trip Time 0.1 to 90.0 Seconds 0.1 111
