69
5 - PARAMETER GROUPS
Number Display Parameter Setting Range Units Default Page
I/O 05 R1 Config R1 Configuration (Relay #1) Off
Fault FS (Fail Safe)
Fault NFS (Non Fail
Safe)
Running
UTS
Alarm
Ready
Locked Out
Overcurrent
Undercurrent
OL Alarm
Shunt Trip FS
Shunt Trip NFS
Ground Fault
Energy Saver
Heating
Slow Spd
Slow Spd Fwd
Slow SPd Rev
Braking
Cool Fan Ctl
Fault FS
112
I/O 06 R2 Config R2 Configuration (Relay #2) Off
I/O 07 R3 Config R3 Configuration (Relay #3) Off
I/O 08 Ain Trp Type Analog Input Trip Type
Off
Low Level
High Level
Off 113
I/O 09 Ain Trp Lvl Analog Input Trip Level 0 to 100 % 50 114
I/O 10 Ain Trp Tim Analog Input Trip Delay Time 0.1 to 90.0 Seconds 0.1 114
I/O 11 Ain Span Analog Input Span 1 to 100 % 100 115
I/O 12 Ain Offset Analog Input Offset 0 to 99 % 0 116
I/O 13 Aout Fctn Analog Output Function
Off
0 – 100% Curr
0 – 200% Curr
0 – 800% Curr
0 – 150% Volt
0 – 150% OL
0 – 10 kW
0 – 100 kW
0 – 1 MW
0 – 10 MW
0 – 100% Ain
0 – 100% Firing
Calibration
Off 116
I/O 14 Aout Span Analog Output Span 1 to 125 % 100 117
I/O 15 Aout Offset Analog Output Offset 1 to 99 % 0 117
I/O 16 Inline Confg In Line Configuration Off, 1.0 to 10.0 Seconds 3.0 118
I/O 17 Bypas Fbk Tim Bypass / 2M Confirm Off, 0.1 to 5.0 Seconds 2.0 118
I/O 18 Kpd Stop Dis Keypad Stop Disable Enabled, Disabled Enabled 119
I/O 19 Auto Start Power On Start Selection
Disabled
Power
Fault
Power and Fault
Disabled 119
To Next Page
