Description of the Keys on the Remote LCD Keypad
4.11 Description of the Keys on the Remote LCD Keypad
The [UP] arrow, [DOWN] arrow, [ENTER] and [MENU] keys on the LCD keypad perform the same functions as the [UP], [DOWN],
[ENTER] and [PARAM] keys on the standard keypad. Three keys have been added, with one of the keys serving a dual function.
53
4 - KEYPAD OPERATION
Key Function
• This key causes the starter to begin the start sequence. The direction is dependent on wiring and phase
selection.
• In order for this key to work, the Local Source (QST 04) parameter must be set to "Keypad".
• Increase the value of a numeric parameter.
• Select the next value of an enumerated parameter.
• It scrolls forward through a list of parameters within a group (when the last parameter is displayed, it
scrolls to the beginning of the list).
• When a list of faults is displayed, it moves from one fault to the next.
• When the starter is in the Operate Mode, pressing [UP] allows you to change which group of meter
values is monitored.
• Decrease the value of a numeric parameter.
• Select the previous value of an enumerated parameter.
• It scrolls backward through a list of parameters within a group (when the first parameter is displayed,
it scrolls to the end of the list).
• When a list of faults is displayed, it moves from one fault to the previous fault.
• When the starter is in the Operate Mode, pressing [DOWN] allows you to change which group of
meter values is monitored.
• When editing a numeric parameter, the [LEFT] arrow key moves the cursor one digit to the left. If
cursor is already at the most significant digit, it returns to the least significant digit on the right.
• When in Menu mode, the [LEFT] arrow allows groups to be scrolled through in the opposite direction
of the [MENU] Key.
• Allows editing a parameter. Stores the change of a parameter.
• When in Fault History, [ENTER] key scrolls through information logged when a fault occurred.
• When an alarm condition exists, [ENTER] scrolls through all active alarms.
• [MENU] scrolls between the operate screen and the available parameter groups.
• When viewing a parameter, pressing [MENU] jumps to the top of the menu.
• When a parameter is being edited and [MENU] is pressed, the change is aborted and the parameter’s
old value is displayed.
• The [STOP/RESET] key halts the operation of the starter (Stop Key).
• If a fault has occurred, the [STOP/RESET] key is used to clear the fault.
• The [STOP] key may be disabled using the Keypad Stop Disable (I/O 18) parameter, if the control
source (QST 04/QST 05) is not set to "Keypad". The [STOP/RESET] key always halts the operation
of the starter if the control source is set to "Keypad". If the control source (QST 04/QST 05) is not set
to "Keypad".
Table 18: Function of the Keys on the LCD Keypad
