61
5 - PARAMETER GROUPS
LED & LCD Display Parameters Cross Reference
5.2 LED and LCD Display Parameters Cross Reference
Parameter
Number
Group Parameter Name Page #
Parameter
Number
Group Parameter Name Page #
P1 QST 01
Motor FLA
75 P42 PFN 11
Auto Reset Limit
104
P2 QST 02
Motor Service Factor
75 P43 PFN 12
Controlled Fault Stop Enable
105
P3
QST 03
PFN 15
Motor Running Overload Class
76 P44 PFN 13
Independent Starting/Running
Overload
106
P4 QST 04
Local Source
77 P45 PFN 14
Motor Starting Overload Class
107
P5 QST 05
Remote Source
78 P46 PFN 16
Motor Overload Hot/Cold Ratio
108
P6
QST 06
CFN 03
Initial Current 1
79 P47 PFN 17
Motor Overload Cooling Time
109
P7
QST 07
CFN 04
Maximum Current 1
80 P48 I/O 01
DI 1 Configuration
110
P8
QST 08
CFN 02
Ramp Time 1
81 P49 I/O 02
DI 2 Configuration
110
P9 QST 09
Up To Speed Time
82 P50 I/O 03
DI 3 Configuration
110
P10 CFN 01
Start Mode
83 P51 I/O 04
Digital Fault Input Trip Time
111
P11 CFN 08
Initial Voltage/Torque/Power
84 P52 I/O 05
R1 Configuration
112
P12 CFN 09
Maximum Torque/Power
85 P53 I/O 06
R2 Configuration
112
P13 CFN 10
Kick Level 1
86 P54 I/O 07
R3 Configuration
112
P14 CFN 11
Kick Time 1
86 P55 I/O 08
Analog Input Trip Type
113
P15 CFN 14
Stop Mode
87 P56 I/O 09
Analog Input Trip Level
114
P16 CFN 15
Decel Begin Level
88 P57 I/O 10
Analog Input Trip Time
114
P17 CFN 16
Decel End Level
89 P58 I/O 11
Analog Input Span
115
P18 CFN 17
Decel Time
90 P59 I/O 12
Analog Input Offset
116
P19 CFN 18
DC Brake Level
91 P60 I/O 13
Analog Output Function
116
P20 CFN 19
DC Brake Time
92 P61 I/O 14
Analog Output Span
117
P21 CFN20
DC Brake Delay
93 P62 I/O 15
Analog Output Offset
117
P22 CFN 06
Initial Current 2
93 P63 I/O 16
Inline Configuration
118
P23 CFN 07
Maximum Current 2
93 P64 I/O 17
Bypass Feedback Time
118
P24 CFN 05
Ramp Time 2
94 P65 I/O 18
Keypad Stop Disable
119
P25 CFN 12
Kick Level 2
94 P66 I/O 19
Power On Start Selection
119
P26 CFN 13
Kick Time 2
94 P67 FUN 15
Miscellaneous Commands
120
P27 CFN 21
Slow Speed
95 P68 FUN 12
Communication Timeout
121
P28 CFN 22
Slow Speed Current Level
95 P69 FUN 11
Communication Baud Rate
121
P29 CFN 23
Slow Speed Time Limit
96 P70 FUN 10
Communication Address
121
P30 CFN 24
Slow Speed Kick Level
96 P71 FUN 13
Communication Byte Framing
122
P31 CFN 25
Slow Speed Kick Time
97 P72 FUN 09
Energy Saver
122
P32 PFN 01
Over Current Level
98 P73 FUN 08
Heater Level
123
P33 PFN 02
Over Current Time
99 P74 FUN 07
Starter Type
124
P34 PFN 03
Under Current Level
100 P75 FUN 06
Rated Power Factor
125
P35 PFN 04
Under Current Time
100 P76 FUN 05
Rated Voltage
125
P36 PFN 05
Current Imbalance Level
101 P77 FUN 04
Phase Order
126
P37 PFN 06
Residual Ground Fault Level
102 P78 FUN 03
CT Ratio
126
P38 PFN 07
Over Voltage Level
103 P79 FUN 01
Meter 1
127
P39 PFN 08
Under Voltage Level
103 n/a FUN 02
Meter 2
127
P40 PFN 09
Voltage Trip Time
104 P80 FUN 14
Software Version 1
128
P41 PFN 10
Auto Fault Reset Time
104 P81 FUN 16
Passcode
129
P82 FL1
Fault Log
130
