P4 Local Source QST 04
LED Display LCD Display
Range LED LCD Description
PAd Keypad The start/stop control is from the keypad.
tEr Terminal The start/stop control is from the terminal strip inputs. (Default)
SEr Serial The start/stop control is from the network.
Description The MX
2
can have three sources of start and stop control; Terminal, Keypad and Serial. Two parameters, (P4
/ QST 04) - Local Source and (P5 / QST 05) - Remote Source, allows the user to change the control source.
If a digital input is programmed as “L-r” (Local / Remote), then that input selects the control source. When
the input is low, the local source is used. When the input is high, the remote source is used. If no digital input
is programmed as “L-r”, then the local/remote bit in the starter control Modbus register selects the control
source. The default value of the bit is Local (0).
See Also Remote Source (P5 / QST 05) parameter on page 78.
Digital Input Configuration (P45-P50 / I/O 01- I/O 03) parameters on page 110.
Keypad Stop Disable (P65 / I/O 18) parameter on page 119.
Communication Timeout (P68 / FUN 12) parameter on page 121.
Communication Baud Rate (P69 / FUN 11) parameter on page 121.
Communication Address (P70 / FUN 10) parameter on page 121.
z NOTE: By default, the Stop key is always enabled, regardless of selected control source. It may be
disabled though using the P65 / I/O18 - Keypad Stop Disable parameter on page 119.
77
6 - PARAMETER DESCRIPTION
QST: Local Src
