5.4.5 Function Group
70
5 - PARAMETER GROUPS
Number Display Parameter Setting Range Units Default Page
FUN 00 Jump Code Jump to parameter 1 to 16 1 120
FUN 01 Meter 1 Meter 1 Ave Current
L1 Current
L2 Current
L3 Current
Curr Imbal
Ground Fault
Ave Volts
L1-L2 Volts
L2-L3 Volts
L3-L1 Volts
Overload
Power Factor
Watts
VA
vars
kW hours
MW hours
Phase Order
Line Freq
Analog Input
Analog Output
Run Days
Run Hours
Starts
TruTorque %
Power %
Pk Accel Cur
Last Start T
Ave Current
127
FUN 02 Meter 2 Meter 2 Ave Volts
FUN 03 CT Ratio CT Ratio
72:1, 96:1, 144:1,
288:1, 864:1, 2640:1,
3900:1, 5760:1,
8000:1, 14400:1,
28800:1
288:1 126
FUN 04 Phase Order Input Phase Sensitivity
Insensitive
ABC
CBA
Single Phase
Insensitive 126
FUN 05 Rated Volts Rated RMS Voltage
100, 110, 120, 200,
208, 220, 230, 240,
350, 380, 400, 415,
440, 460, 480, 500,
525, 575, 600, 660,
690, 800, 1000, 1140
RMS
Voltage
480 125
FUN 06 Motor PF Motor Rated Power Factor
-0.01 (Lag) to 1.00
(Unity)
-0.92 125
FUN 07 Starter Type Starter Type
Normal
Inside Delta
Wye-Delta
Phase Ctl
Curr Follow
ATL
% Normal 124
FUN 08 Heater Level Heater Level Off, 1 to 40 %FLA Off 123
FUN 09 Energy Saver Energy Saver Off, On Seconds Off 122
FUN 10 Com Drop # Communication Address 1 to 247 1 121
FUN 11 Com Baud rate Communication Baud Rate
1200
2400
4800
9600
19200
bps 19200 121
FUN 12 Com Timeout Communication Timeout Off, 1 to 120 Seconds Off 121
