P79 Meter 1 ,Meter 2 FUN 01, 02
LED Display LCD Display
Range LED LCD Description
0 Status Running State. (LED meter only, Default LED meter)
1 Ave Current Average current. (Default LCD Meter 1)
2 L1 Current Current in phase 1.
3 L2 Current Current in phase 2.
4 L3 Current Current in phase 3.
5 Curr Imbal Current Imbalance %.
6 Ground Fault Residual Ground Fault % FLA.
7 Ave Volts Average Voltage L-L RMS. (Default LCD Meter 2)
8 L1-L2 Volts Voltage in, L1 to L2 RMS.
9 L2-L3 Volts Voltage in, L2 to L3 RMS.
10 L3-L1 Volts Voltage in, L3 to L1 RMS.
11 Overload Thermal overload in %.
12 Power Factor Motor power factor.
13 Watts Motor real power consumed.
14 VA Motor apparent power consumed.
15 vars Motor reactive power consumed.
16 kW hours Kilo-watt-hour used by the motor, wraps at 1,000.
17 MW hours Mega-watt-hour used by the motor, wraps at 10,000.
18 Phase Order Phase Rotation.
19 Line Freq Line Frequency.
20 Analog In Analog Input %.
21 Analog Out Analog Output %.
22 Run Days Running time in days, wraps at 2,730 days.
23 Run Hours Running time in Hours and Minutes, wraps at 24:00.
24 Starts Number of Starts, wraps at 65,536.
25 TruTorque % TruTorque %.
26 Power % Power %.
27 Pk accel Curr Peak starting current.
28 Last Start T Last starting duration.
Description For the LED display, this parameter configures which single meter is displayed on the main screen. For the
LCD display, parameters FUN 01 and FUN 02 configure which meters are displayed on the two lines of the
main display screen.
127
6 - PARAMETER DESCRIPTION
FUN: Meter 2
02 Ave Volts
FUN: Meter 1
01 Ave Current
