P33 Over Current Trip Delay Time PFN 02
LED Display LCD Display
Range Off, 0.1 – 90.0 seconds (Default 0.1)
Description The Over Current Trip Delay Time parameter sets the period of time that the motor current must be greater
than the Over Current Level (P32 / PFN 01) parameter before an over current fault and trip occurs.
If "Off" is selected, the over current timer does not operate and the starter does not trip. It energizes any relay
set to Over current until the current drops or the starter trips on an overload.
A shear pin function can be implemented by setting the delay to its minimum value.
See Also Over Current Level (P32 / PFN 01) parameter on page 98.
Auto Reset Limit (P42 / PFN 11) parameter on page 104.
Controlled Fault Stop Enable (P43 / PFN 12) parameter on page 105.
Relay Output Configuration (P52-54 / I/O 05-07) parameters on page 112.
99
6 - PARAMETER DESCRIPTION
PFN: Over Cur Tim
02 0.1 sec
