BENSHAW RediStart RB2 User Manual

Interpreting Model Numbers
Example of Model Number: RX2-1S-361A-14C
A RediStart starter with bypass, MX
2
control, Integrated Bypass, Standard Fault, 361 Amp unit, Frame 14, open Chassis.
6
1 - INTRODUCTION
RB2-1-S-052A-12C
C = Open Chassis
Amp Rating, (0 - 999A)
Frame Size
Fault Level
S = Standard
H = High
Type of Bypass
0 = None (only available with RC)
1 = Integrated
2 = Separate, Definite Purpose (Only with 1000V Starter)
3 = Separate, ATL IEC AC3 Rated
4 = Separate, ATL NEMA Rated (AC4)
Type of Control
2
2 = MX
3
3 = MX
Family of RediStart Starter
B = Bypass
C = Continuous
Figure 1: RediStart MX
2
Series Model Numbers
