APPENDIX E - MODBUS REGISTER MAP
Absolute Register Address Description Range Units
30197/40197
LCD Display Meter 1
1: Ave Current
2: L1 Current
3: L2 Current
4: L3 Current
5: Current Imbalance %
6: Residual Ground Current
7: Ave. Volts
8: L1-L2 Volts
9: L2-L3 Volts
10: L3-L1 Volts
11: Overload
12: Power Factor
13: Watts
14: VA
15: vars
16: kW hours
17: MW hours
18: Phase Order
19: Line Frequency
20: Analog Input
21: Analog Output
22: Running Days
23: Running Hours
24: Starts
25: TruTorque %
26: Power %
27: Peak Starting Current
28: Last Starting Duration
30198/40198 LCD Display Meter 2
30199/40199 Misc. Commands
0: None
1: Standard BIST
2: Powered BIST
3: Reset Run Time
4: Reset kWh
5: Enter Reflash Mode
6: Store Parameters
7: Load Parameters
8: Factory Reset
30200/40200 Bypass Feedback Enable
0: Disabled
1: Enabled
30601/40601 (most recent)
to
30609/40609 (oldest)
Fault Codes Refer to page 196.
30611/40611 (most recent)
to
30619/40619 (oldest)
System States
0: Initializing
1: Locked Out
2: Faulted
3: Stopped
4: Heating
5: Kicking
6: Ramping
7: Slow Speed
8: Not UTS
9: UTS
10: Phase Control / Current Follower
11: Decelerating
12: Braking
13: Wye
14: PORT
15: BIST
16: Shorted SCR Test
17: Open SCR Test
30621/40621 (most recent)
to
30629/40629 (oldest)
L1 Currents: The current that the load is
drawing from Line 1 when the fault has
occurred.
Arms
30631/40631 (most recent)
to
30639/40639 (oldest)
L2 Currents: The current that the load is
drawing from Line 2 when the fault has
occurred.
Arms
