Chapter 6 - Parameter Description [APP]
6-82
Case 2: Dual PID block diagram
Ext.PID Parameter
DRV-20
APP-80
Ext. PI mode
Ext . PID
K
f
Li mit
APP-88
Ext. PID High LImit
Freq.
proc PI dis
APP-90
Gai n
APP-89
Ext. PID Low LImit
Freq.
I/O-20~27
Multi- function Input
Terminal Setting
(M1~M8)
Ext. PID Output
Gai n
Ext. PID F Gain:
Feed Foward
Ext. PID Ref Setting
Zero
APP-93
APP-81
I/O-20~27
Multi- function Input
Terminal Setting
(M1~M8)
APP-83
Ext. PID Run
Zero
APP-82
Ext. Ref Perc
S0, S1 Mode
I/O-70,-72
아날로그 메타 출력 설정
Ext. Fbk Sel
V11
Keypad3
Ext. Ref Sel
PID F/B
Selection
Accel/
Decel
wTarFreq
DRV-14
Target Freq.
APP-
02
proc PI mode
PID
K
f
Limit
APP-10
PID High
LImit Freq.
proc PI dis
APP-12
Gain
APP-11
PID Low
Limit Freq.
I/O-20~27
Multi-function Input
Terminal Setting
(M1~M8)
PID Output Scale
PID F Gain: Feed Foward
PID Aux Ref Setting
Freq
APP-03
APP-04
Aux Ref Mode
APP-05 APP-06
Ext. PID
Aux Ref Sel
8
I
PID F/B
0
1
1
This illustrates dual use of PID controller (APP-02) and External PID controller. Set APP-81 [Ext. Ref Sel] to
Analog Input (V1, I, or Pulse) and connect wiring for analog input. To give the digital reference, set APP-81 [Ext.
Ref Sel] to “Keypad” and set proper value in APP-82 [Ext. Ref Perc]. Set the Ext. PID Feedback among V1, I,
Pulse in APP-83 and connect wiring for analog input. External PID Ref. and feedback are connected to PID
controller. When Ext.PID Run signal is ON to the defined terminal in I/O-20~27, it starts its output. S0/S1 terminal
can be used to connect to another system.
To Next Page
