Chapter 2 – Drive Ratings and Specification
2-18
12) 350HP~400HP,460V
350HP~400HP,600V
RIGHT SIDE VIEW
FRONT VIEW
BOTTOM VIEW
TOP VIEW
27.17
[690.12]
17.70
[449.61]
17.70
[449.61]
27.17
[690.12]
11.43
[290.42]
42.44
[1078.00]
41.08
[1043.51]
17.70
[449.61]
3.19
[81.03]
10.40
[264.03]
27.17
[690.12]
VARIABLE FREQUENCY DRIVEVARIABLE FREQUENCY DRIVE
41.08
[1043.51]
42.44
[1078.00]
460
460
VOLTS
VOLTS
600
600
VFD-RSI-350-SG-4
VFD-RSI-400-SG-4
PART NUMBER
VFD-RSI-350-SG-6
VFD-RSI-400-SG-6
PART NUMBER
350
400
350
HP
400
HP
11.43
[290.42]
10.40
[264.03]
0.35
[8.99]
0.43 DIA.
MTG. HOLES
(2 PLACES)
REMOVABLE SG
LCD KEYPAD
0.43 DIA.
MTG. HOLES
(2 PLACES)
WARNINGWARNING
2.15
[54.64]

BENSHAW RSi SG Series Specifications

General

Brand	BENSHAW
Model	RSi SG Series
Category	DC Drives
Language	English
