BENSHAW RSi SG Series User Manual

Chapter 5 – Parameter List
5-11
PARAM Description
LCD Keypad
Display Setting Range
Factory
Default
Adj.
During
Run Page
I/O-18
Operating selection at Loss
of Freq. Reference
Lost command
None
Free Run
Stop
Protection
None Yes
6-42
I/O-19
Waiting Time after Loss of
Freq. Reference
Time out
0.1 - 120 sec 1.0 Yes
I/O-20
Multi-Function Input
Terminal ‘M1’ Define
M1 define
Speed-L
Speed-M
Speed-H
XCEL-L
XCEL-M
XCEL-H
Dc-brake
2nd Func
Exchange
Reserved
UpDown
3-Wire
Ext Trip
Pre-Heat
iTerm Clear
Open-loop
LOC/REM
Analog hold
XCEL stop
P Gain2
Reserved
Interlock1
Interlock2
Interlock3
Interlock4
Speed_X
RST
BX
JOG
FX
RX
ANA_CHG
Ext PID Run
Up/Dn Clr
Speed-L Yes 6-43
