Chapter 5 – Parameter List
5-12
PARAM Description
LCD Keypad
Display Setting Range
Factory
Default
Adj.
During
Run Page
I/O-21
Multi-function Input
Terminal ‘M2’ Define
M2 define
Same as I/O-20 Speed-M Yes
6-43
I/O-22
Multi-function Input
Terminal ‘M3’ Define
M3 define
Same as I/O-20 Speed-H Yes
I/O-23
Multi-function Input
Terminal ‘M4’ Define
M4 define
Same as I/O-20 RST Yes
I/O-24
Multi-function Input
Terminal ‘M5’ Define
M5 define
Same as I/O-20 BX Yes
I/O-25
Multi-function Input
Terminal ‘M6’ Define
M6 define
Same as I/O-20 JOG Yes
I/O-26
Multi-function Input
Terminal ‘M7’ Define
M7 define
Same as I/O-20 FX Yes
6-43
I/O-27
Multi-function Input
Terminal ‘M8’ Define
M8 define
Same as I/O-20 RX Yes
I/O-28 Terminal Input Status
In status
00000000000
11111111111
00000000000
View
Only
6-44
I/O-29
Filtering Time Constant for
Multi-Function Input
Terminals
Ti Filt Num
2 - 1000 msec 15 Yes
I/O-30 Jog Frequency Setting
Jog freq
0 to FUN-30 Hz.
10 Yes
6-44
I/O-31 Step Frequency 4
Step freq-4
40 Yes
I/O-32 Step Frequency 5
Step freq-5
50 Yes
I/O-33 Step Frequency 6
Step freq-6
40 Yes
I/O-34 Step Frequency 7
Step freq-7
30 Yes
I/O-35
(Note 25)
Step Frequency 8
Step freq-8
20 Yes
I/O-36 Step Frequency 9
Step freq-9
10 Yes
I/O-37 Step Frequency 10
Step freq-10
20 Yes
I/O-38 Step Frequency 11
Step freq-11
30 Yes
I/O-39 Step Frequency 12
Step freq-12
40 Yes
I/O-40 Step Frequency 13
Step freq-13
50 Yes
I/O-41 Step Frequency 14
Step freq-14
40 Yes
I/O-42 Step Frequency 15
Step freq-15
30 Yes
I/O-50
Acceleration Time 1
Acc time-1
0 - 6000 sec 20
Yes
6-46
(for Step speed) Yes
I/O-51
Deceleration Time 1
Dec time-1
0 - 6000 sec 20
Yes
(for Step speed) Yes
I/O-52
(Note 26)
Acceleration Time 2
(for Step speed)
Acc time-2
0 - 6000 sec 30 Yes
I/O-53 Deceleration Time 2
Dec time-2
0 - 6000 sec 30 Yes
I/O-54 Acceleration Time 3
Acc time-3
0 - 6000 sec 40 Yes
I/O-55 Deceleration Time 3
Dec time-3
0 - 6000 sec 40 Yes
I/O-56 Acceleration Time 4
Acc time-4
0 - 6000 sec 50 Yes 6-46
