Bernette DECO B70 - Second Spool Pin Installation

Embroidery preparation
27
2022-08 EN 5020070.40A.04
Second Spool Pin
Installing the Second Spool Pin
> Insert the second spool pin onto the end of the bobbin winding unit (1).
> Align the notch (2) with the spring (3) on the bobbin winding unit.
1
2
3
Inserting Thread Spool
The felt disc prevents the thread from sticking to the spool pin.
> Place the felt disc (1) on the second spool pin.
> Place the thread spool on the second spool pin.
1
