Bernina 1300MDC - Bobbin Case; Winding the Bobbin

10 Operating Instructions
Winding the Bobbin
• the winding speed can be adjusted with
the «+» or «-» in the opened screen or by
turning the stitch width knob
• the motor will stop automatically when the
bobbin is full
•remove the bobbin
Thread Cutter
• cut the thread with the thread cutter
A
To Remove the Bobbin Case
• raise the needle
• turn power switch to «0» (off)
• open the bobbin cover
• grasp the latch of the bobbin case
•remove case
Bobbin Case
To Insert the Bobbin Case
• hold the bobbin case latch
• the finger on the case should point
upwards
• insert so that it clicks into place
• close the bobbin cover
Bobbin Thread Cutter
• insert the bobbin case
• take the thread over cutter A and cut the
thread
The bobbin thread does not
have to be brought up as the
loose end is just the right length
to start sewing.

!
Refer to the
safety instructions!
Winding the Bobbin
• turn power switch to «I» (on)
• place empty bobbin on spindle
Threading the Bobbin
• place thread on spool pin
• attach appropriate spool disc - diameter of
thread spool determines disc size
• following the direction of the arrow, take
thread through the rear guide and around
the pre-tension stud
•wind the thread two to three times around
the empty bobbin and cut off any excess
thread on the thread cutter
•press the engaging lever against the bobbin
• the bobbin winder works automatically
Winding the Bobbin While Sewing or
Embroidering
• place thread spool on vertical spool then,
following the direction of the arrow, take
thread through the thread guide and
around the pre-tension stud
• follow the instructions as described above
for the next steps of winding the bobbin
