8 Operating Instructions
Power Cable
The Power Cable
• plug A into sewing computer
• plug B into wall socket
Foot Control Cable
• plug C into sewing computer
Foot Control
Sewing Speed
• control the sewing speed by depressing the
foot control
• raise or lower the needle by tapping on the
foot control with your heel
Cable Tidy
• wind the cable around the spool
• insert the plug into A
When Sewing
• unwind the cable to the desired length and
slip into B or C
The switch is on the handwheel side of
the sewing computer
I the sewing computer is switched on («I»)
0 the sewing computer is switched off («0»)
The sewing light is switched on and off with
the power switch.
Power Switch
!
Refer to the
safety instructions!
Important!
(USA/Canada only):
Use only foot controller type
LV1 with sewing computer
model artista 630.
Important!
(USA/Canada only):
The sewing computer has a
polarized plug (one blade
wider than the other). To
reduce the risk of electrical
shock, this plug is intended to
fit in a polarized outlet only
one way. If the plug does not
fit fully in the outlet, reverse
the plug. If it still does not fit,
contact a qualified electrician
to install the proper outlet. do
not modify the plug in any
way!
C
B
A
C
B
A
