113Connecting the Adapter
Connecting the Adapter for Free Arm Embroidery (Optional Accessory)
The adapter is used for embroidering tubular items (sleeves, trousers, infant items, socks, etc.)
on the free arm of the sewing computer.
Attaching the Adapter to the Sewing
Computer
• push the adapter behind the free arm
towards the sewing computer so that the
connecting lugs engage in the base plate
of the sewing computer
Attaching the Module to the Adapter
• place the module on the adapter with the
front edge of the module as close as
possible to the L-shaped guide on the
adapter
• push the module towards the guide from
the left until the connecting lugs engage in
the base plate of the adapter
Free Arm Embroidery Hoop
• the small, oval embroidery hoop is specially
designed for free arm embroidery
Caution!
Only the small hoop can be
used for free arm embroidery.
Removing the Adapter
•remove the module from the adapter
• the rear right corner of the adapter is
designed to be used as a grip
• hold the adapter with this grip and remove
from the base plate of the sewing
computer
