Berthoud TRACKER User Manual

82.503 TRACKER / TRACKER-S D.P.A 11
ACTIFLEX suspension in empty tank position ACTIFLEX suspension in full tank position
G
4
2 3
5
3
1
G
Before using your sprayer for the rst time with phytosanitary product (weedkillers,
insecticideorotherproduct),rinsethesprayercompletely.
-Removethenozzlesiftheyaretted.
- Undo the end plugs on the pipes.
- Fill 1/5th of the volume of the tank with water.
- Spray (Refer to the OPERATION chapter of the pump).
-Removeandcleanthelters.
- Retighten the pipe end plugs.
- Fit the nozzles.
NOTE: Any foreign particles which may be in the spraying circuit will thus be eliminated and there will be no
risk of them blocking the holes in the nozzles.
- The patented ACTIFLEX suspension comes as a
standard accessory on the TRACKER-S sprayer.
-Therstspringactionsuspension"delinearized"by
variable stiffness according to the load.
- The ratio and the positioning of a lever arm between
the axle (4) and the base of the spring (5) enable
the spring (3) to constantly adapt to the load (empty
tank/fulltank),toterrainconditions(path,elds,etc.)
for optimal suspension.
- Two shock absorbers (1), between the axle (4) and
the chassis (2), absorb and eliminate any remaining
oscillations.
-
Greaseviathe6greasettings(G)every100hours.
ELF EPEXA 2 or MOBILUX EP2 grease
(Warning: do not use molygraphite grease)
RINSING THE SPRAYER BEFORE FIRST USE
ACTIFLEX SUSPENSION (gure3)
