6 82.503 TRACKER / TRACKER-S D.P.A
DIMENSIONS
ATMOSPHERIC NOISE EMITTED BY: Trailed sprayer TRACKER / TRACKER-S with D.P.A
regulation
 -SoundpressureDriver'senvironmentLPAindB(A):
- Tractor alone = 72.2
- Tractor + sprayer = 72.6
- Sound pressure Peak level:
- Tractor alone = 97.5
- Tractor + sprayer = 100.1
 -SoundpowerLWA:
- Tractor alone = 104.4
- Tractor + sprayer = 106.5
Complywiththelegislationinforceanduseear-protectorsifnecessary.
SOUND MEASUREMENTS
C
B
A
BOOMS
RLD 18 RLD 20 RLD 21 RLD 24 Axiale 24 Axiale 28 Axiale 30 Axiale 32
Overall length
A
6.33 m 6.33 m 6.33 m 6.33 m 7.03 m 7.03 m 8.10 m 8.10 m
Overall height
B
2.90 m 3.00 m 3.00 m 3.30 m 3.50 m 3.85 m 3.90 m 3.95 m
Overallwidth
C
2.55 m to 2.90 m according to tires, track and mudguard option
