Berthoud TRACKER User Manual

82.503 TRACKER / TRACKER-S D.P.A 5
TRACKER / TRACKER-S 3200 D.P.A regulation
Trailedsprayerwithproportionalowratetoadvance(D.P.A.).
- Steel CHASSIS protected by U.H.R. polyester
paint.
- Stainless steel NUTS and BOLTS.
- High-density polyethylene TANK:
- Nominal capacity 3,200 litres.
- Widellingorice.
- RINSE TANK in polyethylene with 330 litres capacity.
- HANDWASH TANK in polyethylene with 20 litres
capacity.
- GraduatedoatGAUGE.
- AXLE adjustable from 1.55 to 2.10 m.
- "ACTIFLEX" SUSPENSION (TRACKER-S):
spring inclined with shock absorbers, ensuring an
independent operation of the load.
- WHEELS:
(*) 420/85 R38 (min. track 1.71 m; max. track 2.09 m).
- MECHANICAL parking BRAKE.
- HYDRAULIC service BRAKE.
- Coupling DRAWBAR with eye.
- Crank-operated JACKSTAND.
- CENTRIFUGAL PUMP for:
 -Filling, agitation with mixing boom, xed rinsing,
transferring, incorporation of trace elements.
- FILLING AND FILTRATION:
- Fillingviathemanholeordirectllingwithcame
lock (diameter 50 mm).
- Incorporation hopper (25 litres) with cans rinse and
circuit rinsing.
- Filtration:
 ▪Fillinglter(sieve,8/10mesh).
 ▪Suctionlter(vannolter,6/10mesh).
 ▪Deliverylter(1/4turnlter,4/10mesh).
TECHNICAL SPECIFICATIONS
- "VOLUX 240" METERING PUMP with 2 double-
acting pistons and 2 drive speeds (including one for
low volume/ha) for the spraying.
- REMOTE CONTROL of the VOLUX pump via
solenoid valve block
- Manual volume/ha ADJUSTMENT on VOLUX pump
(option):
 ▪TELEVOLUX: Remote control of volume/ha with
display.
 ▪BERJUST 2000: In-cab; volume/hectare, speed
and cumulative data information.
- VALVES BLOCK:
 ▪BERLOGIC with DUALMATIC: Manually-controlled
valves block.
- REMOTE CONTROL of spraying operation via
4 stainless motorised ball valves with multireturn units
(option: 5/6/7 motorised valves).
General electrical shut-off switch on cab-mounted
control box.
- ELECTRIC BOX with multi-pin connectors.
- Glycerine PRESSURE GAUGE, 0/25 bar, diameter
80 mm, with dilated scale.
- WIDE ANGLE DRIVE SHAFT.
- HYDRAULIC UNIT (option).
- ROAD LIGHTS in accordance with highway code.
- QUALIFICATIONS:
- Road (DREAL "RegionalOfcesfortheEnvironment,
Planning and Housing"), overall width 2.55 m.
- Environmental compliance.
- OPTIONS:
▪ Adjustable height drawbar.
▪ Hydraulic adjustable drawbar.
▪ Tape gauge.
▪ Electric gauge.
▪ Side door.
▪ Mudguard.
 ▪External washing equipment of sprayer.
 ▪2 work lamps, lighting of the control station,
pre-equipped for gyrolight (AXIALE boom).
 ▪"DiluNet" residual liquid dilution.
Type of tire RLD boom Axiale 24/28
boom
Axiale 30/32
boom
230/95 R48 Standard Standard
270/95 R48 Standard
300/95 R46 Option Option
380/90 R46 Option Option Option
420/85R38(*) Option Option Option
460/85 R38 Option Option Option
