Berthoud TRACKER User Manual

20 82.503 TRACKER / TRACKER-S D.P.A
ADJUSTMENT OF THE COMPENSATED RETURN (V.M.m)
SETTING OF TRACKER D.P.A USING MULTIRETURN UNITS
-Inthiscase,theTRACKERdistributorunitismadeupofmotorisedvalves(V.M.m)(4)(gure9)foreachboom
section.
- These valves supply each boom section when they are in "open" position and the return to the tank when
they are in "closed" position.
-
Return to the tank is calibrated by means of multireturns.
- The setting of the multireturns to the tank is set using the table below because this will depend on nozzle type
used and the number of nozzles per boom section.
TABLE FOR SETTING OF MULTIRETURN UNITS
NOZZLE TYPE
Position of crownwheel (with red numbers)
6
nozzle
section
7
nozzle
section
8
nozzle
section
9
nozzle
section
10
nozzle
section
12
nozzle
section
15
nozzle
section
18
nozzle
section
AFX/RFX/ALX/KWIX - green 80° 1.7 2.0 2.2 2.4 2.5 2.8 3.1 3.5
AFX/RFX/ALX/KWIX - yellow 80° 2.2 2.4 2.6 2.8 3.0 3.3 3.7 4.1
AFX/RFX/ALX/KWIX - blue 110° 2.8 3.0 3.3 3.5 3.7 4.1 4.6 5.1
AFX/RFX/ALX/KWIX - red 110° 3.3 3.5 3.8 4.2 4.3 4.8 5.4 6.0
AFX/RFX/ALX/KWIX - brown 110° 3.7 4.0 4.3 4.6 4.9 5.4 6.1 6.8
AFX/RFX/ALX/KWIX - grey 110° 4.1 4.4 4.8 5.1 5.4 6.0 6.8 7.6
AFX/RFX/ALX/KWIX - white 110° 4.8 5.2 5.6 6.0 6.4 7.0 8.0 8.9
INOX 6/10 - white propeller 0.7 0.8 0.9 1.1 1.2 1.4 1.7 2.0
INOX 8/10 - white propeller 0.9 1.1 1.3 1.4 1.6 1.8 2.2 2.5
INOX 10/10 - white propeller 1.2 1.4 1.6 1.8 1.9 2.2 2.5 2.8
INOX 12/10 - white propeller 1.5 1.8 2.0 2.2 2.3 2.6 2.9 3.2
INOX 15/10 - white propeller 1.9 2.1 2.3 2.5 2.6 2.9 3.3 3.6
INOX 18/10 - white propeller 2.3 2.5 2.7 2.9 3.1 3.4 3.8 4.2
INOX 15/10 - black propeller 2.7 2.9 3.1 3.3 3.5 3.9 4.4 4.9
INOX 18/10 - black propeller 3.1 3.4 3.6 3.9 4.1 4.6 5.2 5.7
INOX 20/10 - black propeller 3.4 3.7 4.0 4.2 4.5 5.0 5.7 6.3
INOX 25/10 - black propeller 3.7 4.0 4.3 4.6 4.9 5.4 6.1 6.7
INOX 30/10 - black propeller 4.2 4.6 5.0 5.4 5.6 6.3 7.0 7.8
KWIX 3-holes - yellow 2.2 2.4 2.6 2.8 3.0 3.3 3.7 4.1
KWIX 3-holes - blue 2.8 3.0 3.3 3.5 3.7 4.1 4.6 5.1
KWIX 3-holes - red 3.3 3.5 3.8 4.2 4.3 4.8 5.4 6.0
KWIX 3-holes - brown 3.7 4.0 4.3 4.6 4.9 5.4 6.1 6.8
KWIX 3-holes - grey 4.1 4.4 4.8 5.1 5.4 6.0 6.8 7.6
KWIX 3-holes - white 4.8 5.2 5.6 6.0 6.4 7.0 8.0 8.9
SETTING THE MULTIRETURN UNITS (gure9)
- Slacken nut (1).
- Turn crownwheel (2).
- Place selected mark in front of index (3).
- Tighten nut (1).
Example:
If Red AFX/RFX/KWIX nozzles are used, and if your sprayer is equipped with a boom of 24 metres (4 sections
of 12 nozzles), you must place the multireturn units at position 4.8.
