38 82.503 TRACKER / TRACKER-S D.P.A
1 ASPIRATION EXTERIEURE
2 INCORPORATION EAU CUVE PRINCIPA LE
3 INCORPORATION EAU ASPIRATION EXTERIEURE
4 INCORPORATION EAU CUVE DE RINCAGE
5 PULVERISAT ION
6 NETTOYAGE CUVE AVEC CUVE DE RINCAGE
7 RINCAGE RAMPE AVEC CUVE DE RINCAGE
8 TRANSFERT
9 NETTOYAGE FILTRE
10 OPTION ASPIRATION AUXILIAIRE
11 OPTION LAVAGE EXTERIEUR
- This option must only be used for cleaning the tank
or rinsing the boom (see page 30) .
▪ Handle of the valve (3) in position
o
(gure32).
▪ Unclipthebrush(1)(gure31).
▪ Connectittothequickcoupling(2).
▪
Put the Berlogic on function
11
(gure 32) and
then beginning cleaning the sprayer .
▪ When done cleaning, put the handle of the valve
(3) in position
f
and correctly clip the brush back
into place after use.
EXTERNAL WASHING DEVICE (Option)
- It is also important to rinse the outside of the sprayer as well as the tractor. This cleaning operation should be
repeated during the day between applications of different products.
PROCEDURE
- Detergent is recommended to facilitate the cleaning operation: All Clear (5 litres), BERTHOUD reference
788.796, All Clear Extra NF (5 litres) BERTHOUD reference 788.792.
- Refer to the detergent manufacturer's instructions regarding exposure time and dilution. To do this, consult
the instructions on the product.
- Generally speaking, spray the product on the machine using a hand sprayer, scrub as required then rinse
with clean water.
EXTERNAL WASHING PROCEDURE
31
32
1
2
3
3
