Berthoud TRACKER - Opening the Fairing

12 82.503 TRACKER / TRACKER-S D.P.A
OPENING THE FAIRING
To open the fairing and reach at the control station:
- Unscrew the 2 threaded rods (1).
- Remove the pins (2) and the clevis pins (3).
- Open the protection door (5) of the control station.
- Rock the fairing assembly (4) forward.
2
3
4
5
1
