28 82.503 TRACKER / TRACKER-S D.P.A
SPRAYING / MIXING / TRANSFERRING
SPRAYING
OPERATION IN D.P.A (Proportionalowratetoadvance)
Centrifugal pump
SPRAYING CONTROL
Put the indexes on Berlogic function
5
.
-
Engage the VOLUX pump (switch or electric selector (4)
(gure18)).
LIQUID MIXING
- Before and during the spraying operation, we
recommend to mix the spraying liquid so as to obtain
a homogeneous product.
NOTE:
Modulate mixing from
-
to
+
.
- Index (1) (gure 19) on
-
= no mixing.
- Index (1) (gure 19) on
+
= max. mixing.
PREPARATION OF THE CONTROL BOX
(gure18)
- With the power take-off stopped:
- Power up the control box by raising switch (1),
lamp (a) lights,
- lift switches (2) and (3).
Yourequipmentisnowreadytowork.
OPERATION
- Engage the power take-off and raise speed to
540 rpm.
TO SPRAY (gure18)
- Lower switches (2) to open the spraying sections,
the lamps (c) lights.
- Lower switch (3) to begin spraying.
TO STOP SPRAYING (gure18)
PARTIAL STOP
- Lift switches (2) corresponding with the spraying
sections you want to cut off.
COMPLETE STOP
- Lift up switch (3).
SPRAYING PRESSURE
The pressure that develops depends on the advance
speedandthenozzlesorice:
- To reduce pressure, decrease your advance speed
ortthenozzleswithbiggerjets.
- To increase pressure, increase your advance speed
ortthenozzleswithsmallerjets.
CAUTION: When not used for spraying operations, the VOLUX pump must be disengaged.
(Actuatetheswitchortheelectricselector(4)(gure18)ontheboomcontrol
box).
NeverengageordisengagetheVOLUXpumpwhiledriving.
TRANSFERRING
TRANSFER OF LIQUID FROM THE MAIN TANK TO ANOTHER TANK
Put the indexes on Berlogic function
8
(gure19).
- To transfer the liquid contained into the tank to another one, proceed as follows:
- Connect the hose to the red quick coupling (R) and put the other end of the hose into the tank to recover
the liquid from the main tank.
- To transfer the liquid, engage the tractor power take-off and raise speed to 540 rpm.
