Berthoud TRACKER User Manual

44 82.503 TRACKER / TRACKER-S D.P.A
Change the oil during each
spraying campaign
LUBRICATION AND GREASING
VOLUX PUMP (gure36)
- The level must reach the notch on the gauge (2).
CAUTION: 2 possibilities of oil capacity according to the position of the VOLUX pump
(see below).
- Item (4): total draining of the pump.
OIL CAPACITY OF THE VOLUX PUMP
 -2litresinhorizontalposition(lowermarkonthegauge(2)).
 -2.5litresininclinedposition(uppermarkonthegauge(2)).
We recommend SAE 30 oil, 2-litre jug, BERTHOUD reference 769.286
 -Item(3):VOLUX pump air chamber.
▪ Check air chamber pressure on the VOLUX pump. The pressure should be 1/3 of the pump's working
pressure.
BEVEL GEARBOX (gure36)
- The level must reach the notch on the gauge (1).
- Item (5): total draining of the bevel gearbox.
OIL CAPACITY OF THE BEVEL GEARBOX
- 1,2 litre.
We recommend SAE 90 oil, TRANSELF TYP B 80 W 90 or MOBILUBE HD 80/90.
SPEED MULTIPLIER (gure37)
 -Thellerplug(1)actsasanoillevel.
- Item (2): total draining of the speed multiplier.
- Check the level, sprayer loaded with the tanks full.
2 possibilities:
▪ Total draining of the speed multiplier; put 2 litres of oil.
▪Levelling;theoilmustbeushwiththeedgeofthehole(item1).
OIL CAPACITY OF THE SPEED MULTIPLIER
- 2 litres.
We recommend SAE 90 oil, TRANSELF TYP B 80 W 90 or MOBILUBE HD 80/90.
-Greaseallthepointsequippedwithagreasenipple(universaljoint,hubs,etc.)
Grease MOBILUX EP2 or ELF EPEXA 2
