Berthoud TRACKER User Manual

36 82.503 TRACKER / TRACKER-S D.P.A
HYDRAULIC STIRRING WITH CENTRIFUGAL PUMP
- Hydraulic stirring permit obtain the production of homogeneous mixtures into the tank, before and during the
spraying operation.
- Refer to the paragraph "LIQUID MIXING" (page 28) for indexes position.
STIRRING
- The pressure gauge (1), situated at the front of the sprayer, above the rinsing tank, can be read from inside
the tractor's cab.
- The valve (1) is directly attached to the VOLUX pump delivery manifold.
It is adjusted to 10 bar pressure.
- The function of this valve is to prevent any overpressure resulting from a mishandled use (liquid hammer).
PRESSURE GAUGE (gure28)
SAFETY VALVE (gure29)
- A running board (1) situated at the front of the sprayer gives access to the man hole.
- During treatment, lift the running board and fold back under the chassis to avoid any damage to the crop.
RUNNING BOARD (gure30)
-Aworkingheightbetween50cmand60cmabovethesurfacetreatedisrecommended.Thisheightisdened
by the nozzle spray angle and spacing.
- There is a risk of drift with greater heights.
HEIGHT OF THE BOOM
- The rinsing balls (1) installed inside the tank, on the gauge tube, ensure this function (refer to the various
rinsing phases, page 30).
RINSING THE MAIN TANK (gure27)
