34 82.503 TRACKER / TRACKER-S D.P.A
-Openthedrainoriceusingvalve(1)whichislocatedundertheequipment,inthesump.
- Collect the liquid in an appropriate recipient.
- You can also empty remaining liquid from the tank into another one (see page 28, paragraph
"TRANSFERRING").
DRAINING THE TANK (gure22)
-Aoatgaugelocatedonthetopofthesprayer’stank,isclearlylegiblefrominsidethetractor'scab.
-Thegaugeiscalibratedusingthesheath(3).
- A graduated rule moves inside a tube.
- To release the graduated rule (2), move the hook (1) to the right or to the left.
-Totransportthetankafterllingit,putthehook(1)onthegraduatedrule(2),inordertoavoidgettingcaught.
FLOAT GAUGE (gure23)
- For hygiene and convenience: An 20-litres water tank (4), independent from the rinse tank, may be used
for rinsing hands and body (face, eyes.) in the event that product is sprayed or splashed on operating
personnel.
- With the tank located on the left-hand side of the sprayer, the tap (5) is easily accessible (behind the protective
plate).
-Washing,byopeningthetap(5)moreorlessaccordingtotherequiredowrate.
-It is ESSENTIAL for the handwash tank to be lled with clean water, through the lid (3), without any
pressure.
HANDWASH TANK (gure26)
-It is ESSENTIAL for the rinsing tank (1) to be lled with clean water, through the lid (2), without any
pressure.
RINSING TANK (gure26)
- A tape gauge (1) located on the top of the sprayer’s tank, is clearly legible from inside the tractor's cab.
TAPE GAUGE (Option) (gure24)
-Yoursprayercanalsobettedwithanelectricgauge(NIVELEC).Itconsists:
 ▪Ofagaugemechanism,item(1),locatedontopofthetank.
 ▪Ofaelectricgaugecontrolunit,item(2).(For information on control unit operation, see manual No. 82.494).
 ▪Ofapowercable(12 Vdc), item (3).
ELECTRIC GAUGE (Option) (gure25)
