PRESENTATION OF THE D.P.A CONTROL BOX
WITH TELEVOLUX (Option)
NOTE:
- Fuse: The control box (2) is protected by 3 type fuses Ø 5 mm x 20 mm:
- 5 Amps for the TELEVOLUX board (item 3),
- 10 Amps for the boom control board (item 4),
- 10 Amps for the boom spraying sections control board (item 5).
4
3
5
TELEVOLUX function
(See manual No. 82.470)
Control box
power switch
1
VOL U X p u mp
engage/disengage
control switch
72 pin plug
Power cable (battery)
Converter plug
Control switches for
options and AXIALE ED
boom
(See manual
No. 82.438)
2
Spraying control switches
(See page 28)
