Berthoud TRACKER User Manual

26 82.503 TRACKER / TRACKER-S D.P.A
FILLING / INCORPORATION HOPPER
FILLING THE TANK
▪Viathetankopening(gravity):
- Open the cover on the top of the tank .
▪ By external suction device:
-Closethedrainoriceusingvalve(1)(gure12)
located under the equipment, in the sump .
- Fill the centrifugal pump priming tank with water.
To do this, remove the square-headed screw (1)
(gure16)locatedontheupperpartofthepump
body.
CAUTION: ALL THE VALVE AND THE INDEXES OPERATIONS MUST BE CARRIED OUT
WITH THE POWER TAKE-OFF STOPPED.
▪Fillingwithoutincorporationhopperusing:
 -Connectthellpipetothebluequickcoupling(B)
(gure14).
- Place the Berlogic indexes in position
1
.
 -Putthellpipeintotheliquidtobesuck.
- Engage the tractor power take-off and raise speed
to 540 rpm.
 -Whenthellingoperationisnished,disconnect
thellpipeandreplacetheplugonthebluequick
coupling (B).
INCORPORATION HOPPER
- This permits introduction, in alternation with water
llingofthesprayer,ofpowdersorliquidtreatment
products.
- This device ensures perfect product homogeneity in
the water, and makes spraying operations easier.
OPERATION OF THE HOPPER
-Fillthetankpartly(seellingoperationabove).
- Pull the hopper towards yourself to lower it. Open
the cover.
- Fill the hopper with phytosanitary products.
3possibilities(gure14):
1 - Water in the main tank used:
Put the indexes on Berlogic function
2
.
2 - Water in the rinsing tank used:
Put the indexes on Berlogic function
4
.
3 - Externallydrawnwater used:
Put the indexes on Berlogic function
3
.
- Engage the tractor power take-off and raise speed
to 540 rpm.
- To rapidly empty the hopper:
▪ Replace the cover,
▪ open the valve (3) to position
o
(gure13).
- The product is draw up into and incorporated in the
sprayer tank.
RINSING THE HOPPER
3 possibilities:
1 - Water in the main tank used:
Put the indexes on Berlogic function
2
.
2 - Water in the rinsing tank used:
Put the indexes on Berlogic function
4
.
3 - Externallydrawnwater used:
Put the indexes on Berlogic function
3
.
In the 3 cases:
-Openthellvalve(4)toposition
o
(gure15)which
actuatestherinsingboom(5)(gure17).
RINSING THE CANS
3 possibilities:
1 - Water in the main tank used:
Put the indexes on Berlogic function
2
.
2 - Water in the rinsing tank used:
Put the indexes on Berlogic function
4
.
3 - Externallydrawnwater used:
Put the indexes on Berlogic function
3
.
In the 3 cases:
- Openthellvalve(4)toposition
o
(gure15).
-Positiontheproductcanonpart(6)(gure17).
-Presshandle(2)(gure13),toactuatethecleaning
nozzle(7)(gure17).
- After the incorporation operation:
▪Closethellvalve(4)toposition
f
(gure15),
▪nishthellingofthetank,
▪whenthellingiscompleted,disconnectthepipe
and replace the plug on the blue quick coupling (B)
(gure14).
