Beta ALP 4.0 User Manual

3
CHECKS AND MAINTENANCE
126
GB
Bleeding the front brake
Follow these steps to bleed the front brake
circuit:
• Remove rubber cap A from valve B.
• Remove the oil reservoir cap.
• Insert one end of a small tube into valve
B and place the other end in a container.
• Unscrew valve B (while pulling the brake
lever) and then pump by repeatedly ac-
tuating the brake lever until oil starts flow-
ing out continuously with no air bubbles.
During this operation, it is important that
the lever should not be released com-
pletely and that the brake pump reser-
voir should be continuously refilled to
make up for the oil that is flowing out.
• Tighten the valve and extract the tube.
• Replace the cap.
ALP
MOTARD
B
A
B
A

Beta ALP 4.0 Specifications

General

Displacement	349 cc
Final Drive	Chain
Rear Suspension	Monoshock
Front Brake	Single disc, 260 mm
Rear Brake	Single disc, 220 mm
Front Tire	90/90-21
Engine	Single cylinder, 4-stroke
