Beta RR 125 LC User Manual

CYLINDER HEAD
EAS24100
CYLINDER HEAD
Removing the cylinder head
Order Job/Parts to remove Q’ty Remarks
Seat/Fuel tank cover assembly/Air filter case
Coolant
Muffler/Exhaust pipe
Clutch cable
Fuel tank
Throttle body/Intake manifold
Radiator
Thermostat/Coolant temperature sensor
Water pump
1 Spark plug cap 1
2 Spark plug 1
3 Crankshaft end accessing screw 1
4 Timing mark accessing screw 1
New
New
New
New
New
New
E
E
(4)
12
11
14
15
16
15
13
6
7
1
2
(4)
(4)
10
9
8
5
4
3
5
E
LS
M
LS
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
7 Nm (0.7 m
•
kgf, 5.1 ft
•
Ibf)
T
.R.
13 Nm (1.3 m
•
kgf, 9.4 ft
•
Ibf)
T
.R.
22 Nm (2.2 m
•
kgf, 16 ft
•
Ibf)
T
.R.
30 Nm (3.0 m
•
kgf, 22 ft
•
Ibf)
T
.R.
*
67 Nm (6.7 m
•
kgf, 48 ft
•
Ibf)
T
.R.
