Beta RR 125 LC User Manual

WATER PUMP
EAS26510
DISASSEMBLING THE WATER PUMP
1. Remove:
• Water pump seal “1”
T
IP
Remove the water pump seal from the inside of
the water pump housing “2”.
2. Remove:
• Bearing “1”
T
IP
Remove the bearing from the outside of the wa-
ter pump housing “2”.
EAS26530
CHECKING THE WATER PUMP
1. Check:
• Water pump housing cover
• Water pump housing
Cracks/damage → Replace.
• Impeller shaft
Cracks/damage/wear → Replace.
• Bearing
Rough movement → Replace.
• Radiator outlet hose
Cracks/damage → Replace.
EAS26560
ASSEMBLING THE WATER PUMP
1. Install:
• Water pump seal “1”
(into the water pump housing “2”)
NOTICE
ECA14080
Never lubricate the water pump seal surface
with oil or grease.
2. Lubricate:
• Water pump seal lip
3.
Install:
• Water pump housing gasket “1”
• Water pump housing plate “2”
• Impeller shaft
2
1
2
1
New
A. Push down
3. Mechanical seal installer
4. Middle driven shaft bearing driver
a. 0–0.5 mm (0–0.02 in)
Recommended lubricant
Lithium-soap-based grease
2
3
4
1
A
New
a
New
