CYLINDER AND PISTON
EAS24350
CYLINDER AND PISTON
Removing the cylinder and piston
Order Job/Parts to remove Q’ty Remarks
Cylinder head
1 Cylinder 1
2 Cylinder gasket 1
3 Dowel pin 2
4 Piston pin clip 2
5 Piston pin 1
6Piston 1
7Top ring 1
8 2nd ring 1
9Oil ring 1
E
E
E
E
New
New
New
New
6
5
4
7
8
4
2
3
1
3
9
7 Nm (0.7 m
•
kgf, 5.1 ft
•
Ibf)
T
.R.
