BALANCER GEARS
EAS22B1008
BALANCER GEARS
Removing the primary drive gear and balancer gears
Order Job/Parts to remove Q’ty Remarks
Clutch housing
1 Primary drive gear nut 1
2 Balancer driven gear nut 1
3Washer 1
4 Primary drive gear 1
5 Balancer drive gear 1
6 Straight key 1
7 Lock washer 1
8 Balancer driven gear 1
9 Straight key 1
10 Spacer 1
1
3
4
5
6
9
7
8
2
10
New
60 Nm (6.0 m
•
kgf, 43 ft
•
Ibf)
T
.R.
50 Nm (5.0 m
•
kgf, 36 ft
•
Ibf)
T
.R.
