WATER PUMP
Disassembling the water pump
Order Job/Parts to remove Q’ty Remarks
1 Water pump housing cover 1
2 Water pump housing cover gasket 1
3 Impeller shaft retainer 1
4 Impeller shaft 1
5 Water pump housing plate 1
6 Water pump housing gasket 1
7 Water pump seal 1
8 Bearing 1
9 Water pump housing 1
LT
New
New
New
LS
1
2
9
7
4
8
3
5
6
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
To Next Page
