THERMOSTAT
EAS26440
THERMOSTAT
Removing the thermostat
Order Job/Parts to remove Q’ty Remarks
Coolant
Fuel tank cover assembly
1 Coolant temperature sensor coupler 1
2 Coolant temperature sensor 1
3 Thermostat cover 1
4 Thermostat 1
5 Radiator inlet hose 1
1
3
4
5
2
New
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
18 Nm (1.8 m
•
kgf, 13 ft
•
Ibf)
T
.R.
