34
ASCENT SCALE
To access the d.i.P Ascent Scale screen, press Both buttons simul-
taneously for 2 seconds while viewing the SN screen, release when
the view only ASC screen appears.
NORM SURF MAIN >> SET NAV >> SET 1 >> SET 2 >> SN >> ASC
• The graphic ASC appears with the graphic indicating the Ascent
Scale (Standard or Navy) that was last selected using the PC In-
terface program (Fig. 35).
> Press Both buttons for 2 seconds to revert to the NORM SURF
MAIN screen.
• Operation reverts to NORM SURF MAIN in 2 minutes if no
button is pressed.
Fig. 35 - ASCENT SCALE
(set by PC Interface)
WARNING: During Activation and Diagnostics, if any display or
function varies from the information presented here, return the
d.i.P to your Authorized Service Technician for inspection.
