NAV DIAGNOSTIC MODE

• Upon manual activation (if NAV was previously set ON and the

d.i.P shut Off), or if the SET NAV screen is accessed from the

NORM SURF MAIN, the unit will enter NAV Diagnostic Mode

(Fig. 60), displaying the NAV segments of the LCD.

• Diagnostic Mode checks the display and battery voltage to en-

sure everything is functioning properly.

• If a Low Battery condition exists, the Battery icon will flash

(Fig. 61a) and the d.i.P will shut Off.

NAV MODE SETTINGS

The NAV Mode Set Menu provides access to the NSN (NAV Se-

rial Number) Preview and PC screens; and to SET MAX DEPTH

ALARM and SET UNITS, which are the same as those described

for NORM settings. Changing the MAX DEPTH ALARM and

UNITS settings in NAV Mode will change the settings selected in

NORM Mode. The NAV Set Menu also includes a SET NAV

BACKLIGHT MODE selection.

Access to the NAV MODE SET MENU:

While viewing the SET NAV screen with ON having been previ-

ously selected (refer to page 55) -

> press/release the A (Advance/Left) button momentarily (< 2

seconds) to step through the Menu selections.

Fig. 60 - NAV DIAGNOSTIC

Fig. 61 - LOW BATTERY
