57
NAV SET MENU
NAV DIVE MAIN (Surface) >> SET NAV (ON) >> NSN >> PC >> SET DEPTH ALARM >>
SET UNITS >> SET NAV BACKLIGHT MODE
NAV SERIAL NUMBER (NSN) PREVIEW
NAV Serial Number Preview is included in the NAV SET Menu for access when NAV Settings
have been Uploaded from the PC program to the d.i.P.
Up to 99 NAV SNs (Serial Numbers or Legs) with CDTs (Count Down Times) up to 9:59:59
(hr:min:sec) and polar SN Headings ranging from 0 to 360 degrees can be Uploaded.
To access the NSN screen while viewing the NAV SET screen,
> press/release the A (Advance/Left) button (< 2 seconds).
• The graphic NSN appears with the Heading (degrees), CDT
(Countdown Time), and SN (Leg #) set by PC Interface (Fig. 62).
> Press/release the S (Select/Right) button to step through the NAV
SNs set from 1 to 99 (or the highest set), or press/hold the button to
scroll through the SNs at a rate of 4 SNs per second.
> Press/release the A (Advance/Left) button (< 2 seconds) to ad-
vance to the PC screen.
> Press Both buttons for 2 seconds to revert to the SET NAV screen.
• Operation will revert to the NAV DIVE MAIN (Surface) screen af-
ter 2 minutes if no button is pressed.
Fig. 62 - NAV SN PREVIEW
